AIT3000 – A neat install by UK Dealer Maricom

We’re starting to see the first AIT3000 installation pictures and here’s a lovely example from Hamble based Maricom.  The AIT3000 is our latest Class B transponder and incorporates a VHF-AIS antenna splitter with our ZeroLoss technology.  Using the main VHF antenna for both VHF and AIS allows for a fast and easy installation as well as offering excellent range as the main VHF will normally be high.

IMG_0422

Note the white GPS antenna cable in the picture above is fitted with a FME connector which is about the same diameter of the coax cable so its easy to run the GPS antenna cable too.  The AIT3000 also features a built in wifi server so AIS, GPS and NMEA data can be streamed to an iPad or tablet.

IMG_0419

Maricom took the screen shot above showing local AIS targets and the boat’s current position shown in red.  There’s lots of apps for navigation afloat including Digital Yacht’s NavLink charting and AIS app for iOS and AISView for Android.  Below is our new MAC app also called NavLink which turns a MacBook into a full featured navigation system with real time positioning, AIS overlays and routing.  It even shows AIS targets scaled to size.

Screen Shot 2014-10-23 at 08.43.55The AIT3000 supports TCP/IP and UDP formats so offers compatability with a huge selection of 3rd party apps too.   The AIT3000 also has NMEA 0183, NMEA 2000 and USB interfaces.

IMG_0417Finally, with the installation complete, the facia panel is replaced and the AIT3000 hidden from view.  A silence switch can also be fitted if required allowing transmissions to be silenced while still allowing AIS target reception.  What a professional install by Maricom.
